The Institute of Advanced Manufacturing Technology (IAMT) was established in the 1990s, which plays an important role in promoting the development of the School of Mechanical School and the key Laboratory for Precision & Mon-traditional Machining Technology of Ministry of Education. IAMT has more than 40 members including 1 academician of Chinese Academy of Engineering, 1 Distinguished Professor of “ Thousand Talents Program”, 1 Principal Scientist of 973 Project, 2 winner of “Cheung Kong Scholars” Program, 2 winner of National Outstanding Youth Fund of NSFC and 2 winners of National Excellent Youth Fund of NSFC. Based on main members of IAMT, an innovative research group supported by NSFC is also founded. IAMT currently has four research directions in machining processes and equipment of complex parts and provides a good research platform for postgraduate students and doctoral candidates. In recent years, IAMT is undertaking or has completed more than 100 national scientific projects including Key Project of National Natural Science Foundation of China and Project of National Basic Research Program of China. Significant innovative achievements have been made in the aspect of manufacturing theories and methods of high-performance parts with complex geometries, ultra-precision machining technologies of functional crystals, additive manufacturing technologies of high performance ceramic structure, precision measuring technologies of geometrical parameters for curved surfaces and moving objects, and high-end equipment manufacturing. These achieved results have achieved significant engineering applications such as the model development and batch production. IAMT has obtained 1 first prize and 2 second prize of national technological invention award, 1 Second prize of National Technology Progress Award and many kinds of awards from ministry and province, has published more than 10 academic works and 350 SCI-indexed journal papers, and has been authorized 150 or so national invention patents. And every year over 10 doctoral candidates and 100 postgraduate students will graduate from IAMT. All these contribute to IAMT’s leading position in the field of mechanical manufacturing.

In addition, IAMT is also in charge of the teaching works of some fundamental courses with respect to machining technology and machine tool design for undergraduate students. Facing to the urgent requirements of precision manufacturing of high-performance parts in aerospace, energy, power and other fields, IMMT is devoted to continually focus on the fundamental research and engineering application, emphasize the feature on the cultivation of innovative talents and the studies in precision, ultra-precision and non-traditional machining, provide original research results and high-level talents in the aspect of advanced machining technology for the development of national manufacturing industry.

Members

D. M. GUO

guodm@dlut.edu.cn

84706059

1stFloor,Advanced Manufacturing LaboratoryBuilding

Z.Y. JIA

jzyxy@dlut.edu.cn

84707882

Room 351-2, Main Building of school of Mechanical Engineering

R.K. KANG

kangrk@dlut.edu.cn

84706059

Room 343, Main Building of school of Mechanical Engineering

H. GAO

gaohang@dlut.edu.cn

84706138

Room216,Advanced Manufacturing LaboratoryBuilding

B. ZHANG

1417890944@qq.com

15140572053

Room214,Advanced Manufacturing LaboratoryBuilding

Y.Q. WANG

yqwang@dlut.edu.cn

84708420

Room 346-2, Main Building of school of Mechanical Engineering

X.M. WANG

xiaoming@dlut.edu.cn

84708411

Room 338, Main Building of school of Mechanical Engineering

Z.Y. YU

zyu@dlut.edu.cn

84707231

Room 305, Main Building of school of Mechanical Engineering

Z.J. JIN

kimsg@dlut.edu.cn

84706519

Room222,Advanced Manufacturing LaboratoryBuilding

M. CONG

congm@dlut.edu.cn

84709200

Room 223-1, Main Building of school of Mechanical Engineering

D.J. WU

djwudut@dlut.edu.cn

84707625

Room 345, Main Building of school of Mechanical Engineering

L.X. CAO

caosm@dlut.edu.cn

84708411

Room 338, Main Building of school of Mechanical Engineering

Y.W. SUN

xiands@dlut.edu.cn

84706751

Room 347, Main Building of school of Mechanical Engineering

X.Y. WANG

wbzzd@dlut.edu.cn

86929050

Room 348-1, Main Building of school of Mechanical Engineering

Y.S. ZHANG

zyshun@dlut.edu.cn

13478625608

Room 319, Main Building of school of Mechanical Engineering

F.J. WNAG

wfjsll@dlut.edu.cn

84707743

Room 351-1, Main Building of school of Mechanical Engineering

Z.Y. ZHANG

zzy@dlut.edu.cn

84709794

1st Floor,Advanced Manufacturing LaboratoryBuilding

W. LIU

lw2007@dlut.edu.cn

84708159

Room 112, Main Building of school of Mechanical Engineering

R. YANG

groupgjw@dlut.edu.cn

84707862

Room 114, Main Building of school of Mechanical Engineering

X.G. GUO

guoxg@dlut.edu.cn

15942684586

Room 349, Main Building of school of Mechanical Engineering

B. NIU

niubin@dlut.edu.cn

84708550

Room 243, Main Building of school of Mechanical Engineering

P. ZHOU

pzhou@dlut.edu.cn，

13478754767

Room228,Advanced Manufacturing LaboratoryBuilding

J.W. MA

mjw2011@dlut.edu.cn

84707876

Room 232, Main Building of school of Mechanical Engineering

Q. BAI

baiqian@dlut.edu.cn

13842856182

1st Floor,Advanced Manufacturing LaboratoryBuilding

Z.G. DONG

dongzg@dlut.edu.cn

13998542604

1st Floor,Advanced Manufacturing LaboratoryBuilding

H.B. LIU

hbliu@dlut.edu.cn

13942842433

Room 106, Main Building of school of Mechanical Engineering

Y.Q. WANG

wangyiqi@dlut.edu.cn

13050579223

Main Building of school of Mechanical Engineering

G.Y. MA

gyma@dlut.edu.cn

13842635966

Room 105, Main Building of school of Mechanical Engineering

S.Y. SUN

sunshy@dlut.edu.cn

13889477112

Room 243, Main Building of school of Mechanical Engineering

S. GAO

gaoshangf@gmail.com

15104088992

Room218,Advanced Manufacturing LaboratoryBuilding

X.L. ZHU

zhuxianglong@163.com

15998535043

Room218,Advanced Manufacturing LaboratoryBuilding

X.P. WANG

xpwang@dlut.edu.cn

13840812194

1st Floor,Advanced Manufacturing LaboratoryBuilding

D. LIU

liudong@mail.dlut.edu.cn

13610864220

Main Achievements

Theory and technology of controllable removal and increasing material machining for complex surface components

The radome should simultaneously process the comprehensive properties of high electrical performance, transparent wave, diversion, heat insulation function, high strength, and complex surface, etc. That means the radome should have both high geometric precision and excellent electrical performance, which brings much difficulty to its machining. Through many years efforts, systemic and practical theories and techniques on machining the radome have been made and a set of precision equipment are invented and been implemented into practice production. These achieved results have obtained 1 first prize of national technological invention award, which is the first time that a mechanical project is received the first prize of national technological invention award in the past 30 years. And these achieved results have also been elected as one of Ten science and technology development of China's Higher Education.

(1)Geometric parameter measuring instrument for the radome (2) Electric thickness measuring instrument

(3) Electrical performance compensation grinding machine

(4)strength selected equipment (5) link ring adhesion equipment

Precision machining of large complex surfaces with associated surface constraints

High performance large complex parts / components are key components of high-end equipment in the field of aviation, aerospace, marine and energy, etc. Its manufacturing capacity comprehensively reflects the manufacturing level of a country, which is also the commanding point of the world manufacturing competition. A new integration method is proposed for large complex surface with associated surface constraints, which includes measurement, surface redesign and digital processing. These achieved results have obtained 1 second prize of national technological invention award.

(1) equipment for honeycomb sandwich structure of lunch vehicle

(2) equipment for cooling channels of the liquid rocket engine

(3) sample parts

Precision machining of high performance composite components

Advanced composite materials (carbon fiber, aramid fiber) have many advantages such as high specific strength, high specific stiffness, outstanding impact resistance, excellent electromagnetic properties, etc. It has been widely used in aerospace, weapons, automobile, power and other fields. But due to its laminated structure, anisotropy, mechanical damage and poor consistency, the machining method of high quality composite components is urgently needed. So the cutting mechanism of carbon fiber composite material is investigated in theory, based on which a series of tools such as milling and drilling for carbon fiber composites are developed and put into engineering use. The actual equipment and its theory research production have passed science and technology achievements appraisal and get the full affirmation.

(1) CNC machine for blind window of large section (2)CNC drilling and grinding equipment for column section (3) TJB component CNC equipment

(4)CNC equipment for combined holes and window of large cylinder composite component (5)radial automatic drilling machine for large cylinder composite component (6) cutting edge equipment for helicopter rotor

(7)CNC equipment for launch canister (8) precision machining machine for super long and narrow seam of cone cylinder parts (9)machining equipment for inner blind holes perpendicular to the connecting holes

Investigation on mechanism for brittle material by single diamond cutting

Nanometric machining mechanism is the basic scientific problem of sub-nanometric accuracy machining and is also an international hotpot. A new single point diamond cutting method with nanometric cutting depth and m/s speed is proposed. The diamond tools with sub micro radius tool edge are developed by using ultra-precision grinding and tribochemical polishing. The related research achievements have been published in CIRP Annals-Manufacturing Technology and Nature series of Journals- Scientific Reports.

(1) The process flow of sub micro diamond tip

(2) schematic of single diamond cutting with 15m/s (3) subsurface damage TEM image

Ultra-precision machining equipment of brittle crystal substrate and optical window

Ultra-precision grinding is the key technology to realize high efficient machining and obtain high precision, super smooth and even damage-free surface for brittle crystal substrate and optical window such as single crystal silicon and sapphire. A new chemical mechanical grinding method based on soft abrasive wheel is proposed. A series ultra-precision grinders for large size wafers of silicon, sapphire and optical window are developed for the first time in China.

(1)300mm silicon wafer ultra-precision grinder (2) ultra-precision thinning grinder for silicon wafers and sapphire substrates (3) double surface grinder for substrates and optical window

(a) Surface morphology of sapphire substrate (b) Surface morphology of silicon wafer (c) Surface morphology after CMG

(d) Surface morphology after CMG (e) Subsurface damage image

(4)surface morphology and subsurface damage of silicon wafer and sapphire substrate after CMG(Ra ≤0.5nm，depth of subsurface damage <20nm)

Precision manufacturing of complex surface parts with macro and micro scale structure

High performance complex surface parts with cross scale structure are the key parts of the high-speed aircraft and are one type of the most difficult machining parts owing to their complex shape, the cross scale structure and anisotropic material. A new self-aligning positioning method based on binocular stereovision is proposed and a new processing technology is developed that combines cladding copper with laser/ NC micro milling. And then the equipment combined on-line visual detection and localization with laser/ micro milling is independently developed to machine different antenna for different high-speed aircraft. The actual equipment and its theory research production have passed science and technology achievements appraisal and get the full affirmation.

(1) The equipment (2) laser machining (3) Positioning (4) Micro milling

(5) sample parts

Fundamental theory of a new tribochemical polishing based on graphitization

It’s well known that although diamond is the hardest known material, it cannot cut transition metal such as Fe, Co, Ni due to extremely rapid tool wear. Based this phenomena, a new tribochemical polishing (TCP) method is proposed in order to meet the high-efficiency and low-damage requirements of polishing CVD diamond film and even sharpening diamond tool. Metal catalyst plays an important role in the process of TCP because of their unique characteristics including unpaired d shell electrons and vertical aligned principle. Molecular dynamics method and the first principle are introduced to investigate the mechanism of graphitization.

(1)Schematic of TCP (2) Unpaired d shell electrons and vertical aligned principle

(3) effect of different metal on the graphitization
